Zebra ZT421 Industrial Printer
Fast and reliable, the ZT421 has a 4.3-inch full-color touch display to see printer status at a glance and quickly make settings changes. It has a print width of 6 inches and can print up to 12 inches per second.
Standard Features
Printing

-Thermal transfer and direct thermal printing

-Thin film printhead with E3™ Element Energy™ Equalizer for superior print quality

-203 dpi print resolution (8 dots / mm)

-Print speeds per second up to 12" (305 mm / second)
Communication
-USB 2.0, high speed
-RS-232 Serial (RS-232C with DB9F connector; Configurable baud rate (2400 – 115,200kB), parity, and data bits. Stop bits at 1 or 2; Software (XON/XOFF), hardware (DTR/DSR or RTS/CTS) communication handshake protocols)
-10/100 Ethernet: Supports networks internally integrated option that enables the use of Webview and Alert features
- Bluetooth® 4.1 (including Apple®)
-Dual USB Host
Media Support
- Dual media sensors — transmissive and reflective
- 3" media supply hanger
- Auto calibration — printer calibrates when printer is turned on or when printhead is closed
Firmware
- Resident ZPL®, ZPL II® and EPL™ programming languages, selectable through software or front panel
- XML-enabled Printing — allows XML communications for barcode label printing eliminating license fees and printer server hardware while lowering customization and programming costs
Operation
• 4.3-inch color touch display with intuitive menu for quick operation and settings management
• Bi-colored status LEDs for quick printer status
• ARM Cortex A7 processor
• 256 MB RAM memory (8 MB User Available)
• 512 MB Flash memory (64 MB User Available)
• Print Touch™ application
• Link-OS®-enabled
• Auto-switching 100-240V power supply
• ENERGY STAR® qualified • Printhead element out detection
Design
• Easy, side-loading metal print mechanism
• Door and print mechanism activated lights to light supplies path
• Tool-less printhead and platen replacement
• Metal media cover with enlarged clear viewing window
• Robust-gold user touch points indicating key adjustments
• Bi-fold media door decreasing overall operating space by 35%

Media Specifications

• Media Types: Continuous, die-cut, notch, black-mark

• Maximum Non-continuous Label Length: 39" (991 mm)

• Media Web Width (Label and Liner): − 2.00" (51 mm) to 7.0" (178 mm) Tear / Cutter − 2.00" (51 mm) to 6.75" (171 mm) Peel / Rewind

• Minimum Label Length: − Tear-off mode: 0.5" (12.7 mm) − Peel mode: 0.5" (12.7 mm) − Rewind mode: 0.5" (12.7 mm) − Cutter: 1.00" (25.4 mm)

• Media Thickness (Label and Liner): − 0.0023" (0.058 mm) to 0.010" (0.25 mm)

• Maximum Media Roll Dimensions: − 8.0" (203 mm) O.D. on a 3" (76 mm) I.D. core

Physical Specifications

Parameter- ZT421
Height 12.75" (324 mm)
Width 13.25" (336 mm)
Depth 19.50" (495 mm)
Weight 40 lb (18.14 kg)
Shipping Weight 45 lb (20.41 kg)
Full Technical Specifications:
